Teledyne LeCroy T3DSO1102 Digital Oscilloscope, 2 Channel, 100MHz, 1GS/s, 7Mpts, 1000 Series

Teledyne Test Tools T3DSO1000 series Oscilloscopes feature both two channel and four channel models.

The two channel T3DSO1102 model is available with a 100 MHz analog bandwidth, a single ADC with a 1 GSa/s maximum sample rate, and a single memory module with 14 Mpts of sample memory.

The T3DSO1102 comes with free enabled serial bus triggering and decode options supporting protocols I2C, SPI, UART, RS232, CAN and LIN.

For ease -of -use, the most commonly used functions can be accessed with its user-friendly front panel design. The T3DSO1102 model come with a 7" Color Display.

• With a waveform capture rate of up to 400,000 wfm/s (sequence mode), the oscilloscope can easily capture the unusual or low-probability events.
• FFT, addition, subtraction, multiplication, division, integration, differential, square root which enables speedy extraction of results from waveforms and measurements.
• 256-Level Intensity Grading and Color Temperature Display. New display technology provides for fast refresh rates. The resulting intensity-graded trace is brighter for events that occur with more frequency and dims when the events occur with less frequency
• History Waveforms (History) Mode and Segmented Acquisition (Sequence). Playback the latest triggered events using the history function. Segmented memory collection will store trigger events into multiple (Up to 80,000) memory segments. Each segment will store triggered waveforms and timestamp each frame.
• Gate and Zoom Measurement. Through Gate and Zoom measurement, the user can specify an arbitrary interval of waveform data analysis and statistics. This helps avoid measurement errors that can be caused by invalid or extraneous data, greatly enhancing the measurements’ validity and flexibility.
