16-Channel High-Speed Multiplexer
- Scanning up to 250 ch/s
- Two- and four-wire scanning
- Built-in thermocouple reference junction
- Includes Certificate of Calibration
The Keysight DAQM902A employs reed relays to achieve scan rates up to 250 channels per second. Use this module for high-throughput automated test applications as well as high-speed data logging and monitoring tasks.
Sixteen two-wire inputs switch up to 300 V. Two- and four-wire channels may be mixed on the same module. User provided shunt resistors are required for current measurements.
Note: Not recommended for connection to ac line without external transient suppression.
Brand: Keysight
Bandwidth: 10 MHz
Channels: 16
For Use With: DAQ970A, DAQ973A
Series: DAQ970A/73A Series
Type: Multiplexer 2 or 4 Wire
Amps: 50 mA
Maximum Voltage: 300 V
Speed: 250 (ch/sec)
