Mixed Signal Oscilloscope 500MHz 2.5GS/s, 4+16 Channel, 10 MB per Channel, Color Display TheTektronix MSO4054B is a 500 MHz, 5GS/s, 4+16 channel Digital Phosphor Mixed Signal Oscilloscope and can analyze up to 20 analog and digital signals in a single instrument to quickly find and diagnose problems in complex designs. Bandwidths up to 500 MHz and a minimum of 5X oversampling on all channels ensure the performance you need to see fast-changing signal details. To capture long windows of signal activity while maintaining fine timing resolution, the MSO4054B offers a deep record length of 20 Mpts standard on all channels. With Wave Inspector controls for rapid waveform navigation, automated serial and parallel bus analysis, limit and mask testing, and automated power analysis, the MSO4054B provides the feature-rich tools you need to simplify and speed debug of your complex design. Bandwidth: 500 MHz Number of channels: 4 analog + 16 digital Sample rate: 2.5 GS/s on all channels Record Length: 20 Mpts on all channels Max. waveform capture rate: >50,000 wfm/s Standard passive voltage probes with less than 4 pF capacitive loading and 500 MHz or 1 GHz analog bandwidth Suite of advanced triggers WaveInspector control, navigation and automated search of waveform data 41 automated measurements, waveform histograms, and FFT analysis TekVPI probe interface 10.4 inch bright XGA color display Connectivity: Two USB 2.0 host ports on the front panel and two on the rear panel for data storage, printing, and connecting a USB keyboard USB 2.0 device port on rear panel for connection to a PC or direct printing to a PictBridge-compatible printer Integrated 10/100/1000BASE-T ethernet port for network connection and video out port to export the oscilloscope display to a monitor or projector
