Rohde & Schwarz MXO 5 Series – MXO54-BNDL Oscilloscope Bundle

Next generation oscilloscope: evolved for more challenges

The R&S MXO 5 series deliver breakthrough oscilloscope technology to speed up understanding and testing of electronic systems.

The specifications for both the 4 and 8 channel models make the R&S MXO 5 series the industry leader in cutting-edge technology for swift and precise results. The oscilloscopes' advanced customized technology and revolutionary features are indispensable for insight into circuit behavior. The impressive 15.6" Full HD capacitive touchscreen and whisper-soft audible operating noise maximize R&S MXO 5 series performance and minimize power consumption.

Key Facts (MXO54):

• Unmatched performance with 2 GHz bandwidth

• 4 Channels

• World’s fastest oscilloscope with > 4.5 million wfms/s update rate and spectrum with > 45k FFT/s

• Industry-leading architecture: 18-bit vertical resolution/12-bit ADC and 10-bit ENOB

• Zone trigger on analog, spectrum and math

• 1 Gpts Memory

Bundle Includes (MXO54-BNDL):

• MXO54 Oscilloscope, 4 channel, 350MHz

• MXO5-B2420 2GHz Bandwidth upgrade

• MXO5-B6 Arbitrary Waveform Generator

• MXO5-B110 Memory upgrade 1 Gpts

• MXO5-K12 Jitter Analysis

• MXO5-K31 Power Analysis

• MXO5-K36 Frequency Response Analysis

• MXO5-K500 Bus Analysis

• Serial Trigger & Decoding:

  • MXO5-K510: I2C, SPI, UART/RS-232 RS-422 / RS-485, Quad-SPI, Custom NRZ

  • MXO5-K520: CAN, CAN-FD, CAN-XL, LIN, SENT

  • MXO5-K530: ARINC-429, MIL-STD-1553, SpaceWire

  • MXO5-K550: SPMI, RFFE, I3C

  • MXO5-K560: 10BASE-T1S, 100BASE-T1

See your signals accurately

With lowest noise and highest vertical resolution on up to 8 channels

• Uncompromising 12-bit ADC for high vertical resolution at all sample rates

• 18-bit architecture with HD mode

• Low noise of 130 μV at 1 mV/div at full bandwidth of 2 GHz

• Full bandwidth vertical scaling down to 500 uV/div with highest offset range of 5 V

Capture even more time

With the deepest standard memory

• Industry’s deepest memory of 500 Mpoints per channel

• Standard segmented memory 10,000 segments

• Standard history mode with 10,000 acquisitions

• Optional memory extension to 1 Gpoints per channel with 1 million segment/memory acquisitions

Superior User Experience

Toolbar, Advanced Uability And R&S SmartGrid

• Toolbar

• Main menu

• Signal activators

• Pop-up selection provide a list of interactive elements

• Large touch field design

• R&S SmartGrid function

• Signal icon

• Cursor labels

• Tab display

In The Box:

• R&S MXO54 Oscilloscope

  • Application Bundle

• 700 MHz 10X Passive probe - 1 per channel.

• Accessories Bag

• Quick Start Guide

• Power Cord
