SKS Hirschmann Test & Measurement VSB 20 gruen / green Banana Plug, Grey, 4mm, Stackable, Screw, 30A
Part #NS04 930435104
MFG #VSB 20 gruen / green
SKS Hirschmann Test & Measurement
SKS Hirschmann Test & Measurement VSB 20 gruen / green Banana Plug, Grey, 4mm, Stackable, Screw, 30A
Part #NS04 930435104
MFG #VSB 20 gruen / green
£
£
Multiples of: 50
- Description
- Attributes
- Documents
Fully mating connector with cable gland and 4 mm socket for onward connection capability. Screw connection up to maximum cable cross-section of 2.5 mm² and external diameter of 4 mm. Nickel-plated brass contact material.
Brand:Â SKS Hirschmann Test & Measurement
Type:Â Banana Plug
Series:Â VSB Series
Alternate Product Number:Â 930435104
AC Voltage:Â 30 V
Color:Â Green
Connection:Â Screw Terminal
Current Rating:Â 30 A
DC Voltage:Â 60 V
Housing Material:Â PP
Material:Â Brass, Nickel Plated
Pin Size:Â 4 mm
Style:Â Stackable
Temperature Range: -25 to +70°C
Terminal Type:Â Screw
US SKU #:Â 10117642
Voltage Rating:Â 60 V
£
£
Multiples of: 50
