Pomona
Pomona 5360-2 SMD Grabber Test Clip w/.025" Sq. Pin, 1.73" Long, 0.5 A, 60 V, Red, 5360 Series
Part #34045.1
MFG #5360-2
Pomona
Pomona 5360-2 SMD Grabber Test Clip w/.025" Sq. Pin, 1.73" Long, 0.5 A, 60 V, Red, 5360 Series
Part #34045.1
MFG #5360-2
£
£
Multiples of: 5
- Description
- Attributes
- Documents
- The SMD Grabber Test Clip is especially suited for testing surface mounted packages on centers as small as 0.635mm (.025in).
- Pincer-like contact grasps individual legs of SMD’s such as the SOIC, SOJ, PLCC, etc.
- Its circular design and small size have been developed for easy use and handling.
- Mates with Model #4772 or 4741 square pin receptacles.
- The Square Pin Material is Phosphor Bronze.
- The Square Pin Finish is Gold Plated.
Brand:Â Pomona
Series:Â 5360 Series
Color:Â Red
Contact Finish:Â Gold Plated
Contact Material:Â Stainless Steel
Current:Â 0.5 A
Insulation:Â Glass filled Nylon
Maximum Temperature: 216°F
Quote Required:Â No
Voltage Rating:Â 60 V
£
£
Multiples of: 5
