Pomona 4773-2 Pin Tip Jack, 3 A, Miniature, Wrapped Wire Terminal, Red, 4773 Series
Part #35366.1
MFG #4773-2
Pomona
Pomona 4773-2 Pin Tip Jack, 3 A, Miniature, Wrapped Wire Terminal, Red, 4773 Series
Part #35366.1
MFG #4773-2
£
£
Multiples of: 10
- Description
- Attributes
- Documents
- Accepts .080 dia. pin
- Max. panel thickness .25.
- Pin Jack Insulation: Polycarbonate molded to Pin Jack Body.
- Panel Insulator: Polycarbonate. Color matches color of Pin Jack insulation.
- Lockwasher #8 Internal Tooth: Steel, Finish: Nickel plated per QQN-290, latest revision, Class 2, 200/300 microinches.
- Hex Nut #8-32: Brass, Finish: Nickel plated per QQN-290, latest revision, Class 2, 200/300 microinches.
- Pin Jack Body: Nickel Plated Brass latest revision, Alloy 360, ½ Hard.
- Spring: Gold Plated Beryllium Copper, Berylco 25 per QQC-533, latest revision, Cond. HT.
- Finish: Body Electroless nickel plated per MIL-C-26074, latest revision, Class 2, 200/300 microinches.
- Spring: Gold plated per MIL-G-45204, latest revision Type II, Class 00 over electroless nickel per MIL-C-26074, latest revision, Class 1, 200/300 microinches.
- Wrapped Wire Terminal: Gold Plated Phosphor Bronze
- Finish: Gold plated per MIL-G-45204, latest revision, Type II, Class 00 over electroless nickel per MIL-C-26074, latest revision, Class 1, 200/300 microinches.
Brand:Â Pomona
Series:Â 4773 Series
Color:Â Red
Current:Â 3 A
Finish:Â Gold Plated
Insulation:Â Polycarbonate
Material:Â Brass
Maximum Temperature: 239°F
Mounting Type:Â Panel Mount
Quote Required:Â No
Voltage:Â 1500 V
£
£
